Outdoor Red 7 Segment Display Screen LED Gas Station Sign Board
| Place of Origin | SAHNDONG QINGDAO |
|---|---|
| Brand Name | autodisp |
| Model Number | D2-R240-88.88 |
| Minimum Order Quantity | 1 |
| Price | USD166~175piece |
| Packaging Details | Cardboard boxes |
| Delivery Time | 15 working days |
| Payment Terms | T/T |
| Supply Ability | 500 pieces per month |
Product Details
| Usage | Gas Station | Panel Size | 880*370*25mm（Customizable） |
|---|---|---|---|
| Color | Red/Green/Yellow | Function | Gas Price Display |
| Brightness | Maximum Brightness >7000mcd | Warranty | 3 Years Warranty |
| Operation | Remote Control | Font | 8.889/10 8.888 8.889 888.88 88.88（Customizable） |
| Voltage | DC 24v | Degree Of Protection | IP65 |
| High Light | Outdoor 7 segment display screen,DC24v 7 segment display screen,88.88 gas station sign board |
||
Product Description
Outdoor 7 Segment Red Led Screen Waterproof LED Display Board For Gas Station
Description:
LED price tag is currently the mainstream way for gas station price display, and its clear and eye-catching visual effect has been fully recognized by the international market. Our products adopt the whole sealant waterproof technology, outdoor performance is excellent. Low power consumption and constant current technology are introduced to greatly reduce the failure rate, improve the service life of the product, and ensure the all-weather operation of the product.
Specifications:
| LED price unit | Specifications | System control | Specifications | Remote control | Specifications |
| IP-value housing | IP65 | IP-value housing | IP23 | Operating temperature | -15~50℃ |
| Angle | Horizontal≥80°,Vertical≥40° | Input voltage | 100~240VAC | Communication mode | 470M radio frequency communication |
| Voltage | DC24V | Output voltage | DC24V |
Operating model |
Numeric keyboard |
| Unit thickness | 25mm | Output power | 240W | Program Display | LCD |
| Panel material | Aluminium, black powder coated | Backlight control power | 3000W | Adjust the distance | Open area ≥ 300m,Blocking area≥30m. |
| LED current | Constant current Imax<20mA | Operating temperature | -30~60°℃ | Charging standby time | ≥3months |
| MTBF-factor | ≥20000H |
Control mode |
Remote control or Remote transmitter | Voltage | DC5V |
| Operating temperature | -30~60℃ | MTBF-factor | ≥20000H |
Charging port |
microUSB |
| Average power | 240 series <15W | Backlight control VPT | 100Lux |
|
Advantages:
-
Fully sealed core electronics, waterproof, sun-proof and strong heat dissipation
-
Modular design for easy installation and retrofitting
-
Use A-grade wide angle lamp beads, display brightness is 1.5 times that of the screen, lamp bead life of 100,000 hours
-
Ultra-thin and lightweight design for easy installation and maintenance
-
Support remote price adjustment, safe and convenient
Applications:
The LED price board can clearly display the oil price of various oil products, and automatically adjust the brightness of the lamp beads according to the light intensity during the day, which really saves energy and electricity.
Case:
